If The input voltage is in the range of 210-250v the regulator is able to provide 100% listed maximum output power.Maximum output power Will change as the curve shown below
| Technology |
Relay Control System+Programmed control computerized + control algorithm relay“Cross zero” |
| Input voltage | Single phases: 175-265V Three phases four-line |
| 175V-265V( phases voltage) 304V-456V(Line -voltage) | |
| 154V-286V(phases voltage) 270V-490V(Line -voltage) | |
| Output voltage | Single phases:220V;Three phases:380V; |
| Output deviance | 1-5%( Adjustable) |
| Frequency | 50-60Hz |
| Efficiency | ≥95%(Power > 50KVA) |
| Response time | ≤1.5S |
| Ambient temperature | -10°C~+40°C |
| Insulation resistance | ≥5MΩ |
| Electricalintensity | Without breakdown and |
| flashover phenomena at power frequency sine voltage 2000V for 1 min | |
| Overload | Double rated current,one min |
| Waveform distortion | Non-lack fidelity wareform |
| Protect | Overvoltage,overcurrent,feed phases |
